Lynde, Carleton John, b. 1872 · New York : Macmillan · leaf 242
\ I I … FiG. 164.— A commercial direct-current dynamo. F has six poles. These are alternately north and southpoles. The armature B B, shown on the right, is a drumarmature. It consists of many coils wound lengthwise on asoft iron drum. The coils are attached to the strips of thecommutator in series. A…
Physics · Home Economics
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
