Dunkerley, Stanley, 1870- · London, New York [etc.] Longmans, Green · leaf 148
Fig. 144. … Fio. 14S. are mathematically accurate in the line of stroke, but in whichthere is a slight error in the displacement of the drum due to thevarying obliquity of the cord. Fi». 144 is a modification of Pig. 143, in which the slot i8replaced by a lever, QB, so that the locus of B is a circular arc 38…
Machinery, Kinematics of
