Slack Side e-B:- of Cfixizn. Fio. 331. Fta. 332 wheel, and the pins have a considerable back-lash in the spacesbetween the teeth; the result is that, at any instant, aU the force comes on one pin, namely, upon … Tiglti, Side ,-e-e- the pin which receives or deliversthe slack side of the chain (seeFig. 331). As the chain stretchesor the pins wear, the pitch getsmore nearly equal to the pitchof the wheel (Fig. 332), and atsome particular instant, each pinis driving equally. As the pitchof the chain still…
