figures the bottom tangent a was level, while inFig. 103 it inclines equal to the pitch of the upper tangent b and of theflight adjoining. Inother words, themethod shown inFig. 101 is appliedto a construction inwhich the wreath isramped; while inFig. 103 the methodis applicable to a Qroundwreath… … Fig. 110. Finding Bevels for Wreath with Two EquallyInclined Tangents. 323 60 STAIR-BUILDING The foregoing examples cover all conditions of tangents that are likely to turn up in practice, and, if clearly understood, will enable the student to lay out the face-moulds for all kinds of curves. Bevels…
