r~^ w «/ 1 .n FM … 106 MECHANICAL DRAFTING 107 the edge a-f is shown as the T-square line a^-x.The plane 1-2-6-5 is seen edgewise in line 1^-2,and cuts a^-x at point o. The point o on edge a-f is at a distance a^-0^higher than the edge 1-5; hence ihe lengtha^-o^ is laid off in elevation above 1-5, locatingo. The…
