Fig. 316. Fig. 317. to E F, and through the figures, draw lines, which intersect with linesdrawn at right angles to EO from similarly numbered intersections onKEF and NOP. A line traced through the points thus obtained, asshown by U° E° F° and N° 0° P° will be the pattern for D and A. For tlie…
