ctT^ -V … Fig- 8. Fig. 9. Consequently, most draftsmen place shade lines on all lines whichrepresent lower and right-hand edges if these edges are sharp. The contour linss of cylinders, cones and other rounded sur-faces should not be shade lines, although some draftsmen shade them.If the cylinder is drawn in…
