Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 132

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 132
ses. If any one of the three parts isnot level when the rest are, the results are uneven cloth, yarn brokenout, and very poor shedding. A greater or a smaller number ofpicks can be placed in the cloth, according to the way in which theharnesses are set. With a shed level when the reed is from two… … Fig. 67. Position of Cam When Shed is Ch)sed. only one pick to beat up at a time; but with a shed which is not scopen, the picks are not held firmly, and spring back so that the layhas to beat up several at one time. This makes it impossible tohave as heavy a cloth as in the former case. When…

Textile industry · Textile fabrics
