Fig, 331 F/g. 332 and left hand corner of the sheet at an angle of 45°, and to lie inthe plane of the paper. The lower and right hand edges wherethe Hght passes over them are made heavy lines called shadelines. When two surfaces are in the same plane the line of divisionbetween them is not shaded,… … it bounds (C, Fig. 321). Most all conditions of shading areillustrated in the figures given in this chapter, which shouldbe carefully studied. SHADE LINE DRAWINGS 139 Surface Shading. — Various methods of hne shading on surfacesare used to show the shape of machine parts. Personal judgmentis an…
