. Gun-metal Tail-guide for Valve Rod.—Figs. 473, 474 showtwo views of a guide you may have noticed projecting from theend of the slide-valve jacket of a steam engine ; its function is tosteady and keep in its place the end of the valve rod, so that thevalve may not leave the face upon which it…
