een I into passage 10, which communicates with the ‘annular expansion nozzle formed between nozzle 11 and On board a ship it is necessary to install a surface nozzle point 12. Nozzle point 12 may be adjusted toward inter-condenser. The heat contained in the steam of the first stage is entirely… … has derived its name), which has a greater penetrating Fig. 11.—Comparative Outlines of Twin Beam Air Pump and Air force and larger entrainment surface than that of a Ejector cylindrical jet of equal length. Consequently better effi- ciencies are obtained. condensate from the inter-condenser.…
