Bradbury, F. (Fred) · Manchester : John Heywood Ltd. · leaf 236
inches,equal to the pitch between the shuttle centres. The details of themechanism which facilitates this lateral movement are as follows:—A movable rack 22, with leather teeth, ^in. pitch, is fitted into agroove 23 at the back of the swivel frame 12, Fig. 242 ; along thisgroove the rack is free to… … 232 JACQUARD MECHANISM AND HARNESS MOUNTING. the rack pinion 24 in turn, gear into the teeth of a small rack 26compounded with the lower and rear side of the swivel shuttle 17.Each shuttle is similarly combined with.and controlled by the rack22. This rack is combined with a projecting flat iron…
Textile machinery
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
