s shown in Plate49, are as follows: I. Reverse Lever. ii. Strap. 2. Reach Rod. 12. Blade. 3- Reversing Arm. 13- Link Block. 4- Tumbling Shaft. 14. Link Block Pin. 5- Lifting Arm. 15. Top and Bottom Rock- 6. Link Hanger. er Arm. 7- Link Saddle. 16. Valve Rod. 8. Pin. 17. Valve-Stem. 9- Link. 18.… … 0) the manner in which they are connected. When thethrottle is open, steam passes by throttle valve A in the 174 VALVE MOTION. dome, through stand pipe B; to dry pipe C, through thedry pipe to the nigger-head D in the smoke arch and
