Locomotive text for engineers and firemen; a complete treatise on the engine, electric head-light and standard code of train rules (1908)
National correspondence school of railroading, Chicago. [from old catalog] · [Chicago] · leaf 52
Jet Valve Bonnet and 139. Coupling Nut (water Nut end) Il6. Jet Valve Gland 139-a . Tailpiece (water 117. Jet Valve Lever end) Handle 140. Coupling Nut (deliv- Il8. Jet Valve Top Nut ery end) 118-; 1. Jet Tube 140-a . Tailpiece (delivery 118-b. Lifting Nozzle end) 119. Water-Valve 141.… … mma iWMJ/WSJB. PLATE 2.NATHAN MONITOR XX INJECTOR 42 LOCOMOTIVE INJECTORS. Water-valve 119 is opened by means of lever 123,which admits water into chamber 141; valve 113 is thenopened by means of lever 117, which admits steam intotube 118-a, escaping into the overflow, thus creating apartial vacuum…
Locomotives
