6, Figure / HANCOCK INSPIRATOR delivery chamber of the lifter is increased, enabling thewater to enter the forcer combining tube against the in-creased pressure of steam from the forcing nozzle, thusenabling it to work from low pressure to high pressure 54 LOCOMOTIVE INJECTORS. without any… … FIG. 2—PLATE 6.HANCOCK INSPIRATOR at its minimum. This indicates an insufficient steam sup-ply. It may be due to contracted openings in the valvenext to the boiler, combination box, or the dry pipe lead-ing to the combination box being too small, which shouldbe remedied. An insufficient supply of…
