Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 149
accurate curve, having beendeveloped, may be transferred by the tracing-cloth method, as incams, to each individual tooth; or arcs may be found by trial whichapproximate to the true curve; or a templet of stiff paper or card-board may be made. Design of Epicycloidal Gears. Fig. 114 shows a pair of… … MACHINE DRAWING 137 shown dotted, by rolling on the inside of the pitch circle of the gearB, generates the hypocycloid PE, which forms the flanks of the teethon gear B; and by rolling on the outside of pitch circle of gear A,generates the epicycloid PF, which forms the faces of the teeth ongear A.…
