ome of the smaller appliances used about the shop should be familiarto the draftsman. Some usual clamps are shown in Fig. 195. If stand-ard equipment is on hand this is a simple matter that can often be used toadvantage when deciding on how to hold a machine part for finishing. JIGS, FIXTURES, AND… … Fig. 196. Holding Devices Applied. 197. Drawings and dimensions were furnished by Mr. H. Cadawallader,Jr., of the Standard Shop Equipment Co., Philadelphia, Pa. Such de-
