FIG. 133. THE PUTNAM ENGINE 131 … T ON 132 VALVE SETTING lator; the new-style regulator, Fig. 136, is somewhat different and isoperated in the following manner: After all the connections have beenmade, raise the balls until the clearance S, between the center weight andthe collar, is ^ of an inch. Hold in that position and push the…
