A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)
Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 440
iven crank angle, when the distance between the points of the dividerswill evidently be the length of a line representing the corresponding rotativeeffect. Perpendiculars to the base line at short intervals render it easy tomeasure distances vertically with the dividers. With a diagram of… … In Figs. 806/, 8o6f, 0d CD A and 0 a A C SiVe intended to representthe true indicator diagrams taken from the two ends of a cylinder, the linestraced at the same time at opposite ends of the cylinder being combined ineach diagram, and it is required to deduce from these diagrams the corre-sponding…
Mechanics, Applied · Mechanical engineering
