Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 93

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 93
201. Longitudinal section, showing ball bear-ing, overlap of the jaws, wedges, and volutecap. 202. Shows the alternate jaws, wedges, andthe volute cap for tightening the wedges. … 203. NOVEL VALVE GEAR. The crank-pin arm is pivoted to the lever R at E, and tothe link block B, and also to the valve rod asshown. The motion of the valve is controlledand reversed by rocking the link L. STEAM POWER APPLIANCES. 93

Mechanical movements
