ts the motion of the piston rod toelliptical gears (not shown in the engraving),which controls the motion and transmitsthe power of the engine. The cyHnders with the steam pipe, /, arecarried by a bracket, H, which is keyedfirmly to the main shaft, A, and rotates with it. The radial arms, K K,to… … STEAM IOWKR APPLIANCES. 109 through the ports, ?, at either end of the cyhnders, the difference inthe diameters of the elHptical gears at the point of contact causes themain shaft elhptical gear, with the attached parts, to rotate.
