261. ROTARY ENGINE. Casadays pat-ent. A reversing rotary with adjustable cut off.A is the cut-off plug within an adjustable rotablecylinder and operated by an arm and connectingrod to the eccentric or the plug rotated bysprocket and chain. D, reversing plug. H, abut-ment block, cushioned by steam… … 262. REVERSIBLE ROTARY EN-GINE. The piston when revolving in thedirection of the arrow takes steam by thethrow of a two-way cock; steam enteringthrough the diagonal slots in the abutmentpieces at /, /, and exhausting through theports e, c. Reversed by throwing over thesteam-cock opening to the…
