Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 92

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 92
which shortens the stroke of thevalves and consequently changes the point of cut-off in the cylinder. STEAM POWER APPLIANCES. 89 186. CORLISS VALVE GEAR and release mechanism, stand-ard type. A, valve stem. A bell crank operated by a connecting rod fromthe wrist plate, lifts the grab hook, E, and… … TO WRIST PUTE 187. CORLISS VALVE GEAR and release mechanism. Thegrab hook consists of a block, C, sliding in a grooved slot in the bell-crank lever B B, and normally forced out-ward by a spring. The block C carries apin, E, on the rear side, which is held in_^^ contact with a cam ring, F, having…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
