ley will onlyrotate when the band, B, is tight on the boss, C.When used as a shaft coupling the boss, C, is pro- 106 MECHANICAL DRAWING longed and keyed to one of tlie shafts, the sleeve,A, being keyed to the other. Cone Friction Clutch. The friction clutch,shown in Fig, 195, although simpler in… … Fig. 195—Cone Friction Clutch. causes an objectionable end thrust. The mean di-ameter of the conical part may be from four toeight times the diameter of the shaft, being largerthe greater the amount of power which the clutchhas to transmit. The inclination a of the slantside of the cone to its axis…
