Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 216

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 216
ms in either aninner or outer position a pin is passedtransversely through apertures inthe hub flanges and through one ofseveral apertures in the wheel onwhich the sliding arms are pivoted, the wheel being turned to theproper position before inserting the pin, while the passing of a pinthrough the… … 212 ROAD AND VEHICLE DEVICES, 17 I

Mechanical movements
