Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 240

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 240
their opposite focii,to which the link A, P, B,is attached. P, the pencil,which on moving from thecenter of the link, will pro-duce a great variety of curves. 609. CIRCULAR FROMRECIPROCATING MO-TION. A lever L, moved byany reciprocating power, op-erates the pawls on the meshedgear A, B, for a… … 2:6 BEARING AND GEAR MOTION. ETC.

Mechanical movements
