Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 247

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 247
and efficient medium for joining two shafts. The sprockets are verysimilar to spur gears and the chain links have projections whichengage in the tooth spaces. … 630c. MOTOR-VEHICLE STEERINGGEAR. Worm gearing as shown is widelyused for transmitting the motion of thesteering wheel to the front wheels of auto-mobiles and tractors. The use of a wormmakes it easy to swing the wheels andprevents road shocks being transmitted tothe driver, because the worm…

Mechanical movements
