Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 68

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 68
ombines them and spreadsthem outward at the same time.\^ The air pipe connects with, achamber D, which has a cockfor draining off water. A valveis provided between D and C forcontrolling the pressure. Theoil pipe connects to the back ofC, and is carried through C by apipe G which terminates with… … 114. OIL FUEL BURNER.

Mechanical movements
