Mechanical drawing for secondary schools (1916)

Crawshaw, Fred D. (Fred Duane), b. 1874, Phillips, J. D. (James David), 1869- joint author · Chicago, New York, Scott, Foresman and company · leaf 157

An illustration from Mechanical drawing for secondary schools, 1916, leaf 157
Fig. 159. Stationery and Ink Stand 152 MECHANICAL DRAWING DATA FOE LETTERING PLATE 16 Given: Plate 16 to reduced size. Fig. 161. Required: To make the plate in ink to an enlarged scale. … Fig. 160. Clamp DATA FOR DRAWING PLATE 17 Given: The orthographic sketch, Plate 16.Required: To make a pencil mechanical drawing fromPlate 16. Instructions: 1. Draw the border line and enclosing rectangle. 2. Locate and draw two center lines at right angles to eachother for each arc or circle.…

Mechanical drawing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
