Mechanical drawing for secondary schools (1916)

Crawshaw, Fred D. (Fred Duane), b. 1874, Phillips, J. D. (James David), 1869- joint author · Chicago, New York, Scott, Foresman and company · leaf 223

An illustration from Mechanical drawing for secondary schools, 1916, leaf 223
elop into a straight line. Thelength of this line may be determined, as before, by dividing the 218 MECHANICAL DRAWING base circle into a number of equal small divisions and steppingthem off with the dividers. To obtain the development of the lineof intersection, elements are drawn in the surface… … Fig. 241. Type Problem. Intersection of a Square Prism and aCylinder of the dividers or projected by horizontal lines as shown inFig. 241. The pattern for the entire surface of the prism is laid out asm Plate 24. The hole opening into the cylinder or the line ofintersection is determined in the…

Mechanical drawing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
