to takea, set of plans and from those plansmake views of the work indicated,as it will actually appear. We donot mean to infer that every plan ofordinary work will receive this attention nection with the drawing from houseplans, the figuring of stock on the samework. In Figs. 78, 79 and 80 we show… … Fig. 78—Cellar Plan, Double House. from the plumber who is able to makesuch drawings, but even though heshould seldom put his knowledge of thesubject into actual use, the insight he hasgained concerning the relation of plansand elevations will help him wonderfullyin the figuring of work. This leads…
