Mechanical drawing for industrial and high schools (1915)
Leeds, Charles Carley, 1870- · New York, D. Van Nostrand company · leaf 80
end than at the other. By this time the student should be sufficiently familiar with handwheels to need no instruction on this subject. The binding screw shown is an illustration which shows the valueof a knowledge of shop practice. This screw is machined in a lathein the manner shown by the solid… … 16 Thd. per in. class Industrialname. John W. Roberts date Dec. 30- 07. The Carnegie /institute or Technology PITTSBURGH. Pa. IP Speed LatheTailstock Details scale Full Size DW5.No. C.i037 LESSON No. 35. TAILSTOCK DETAILS.—The rest of the details of the lathetailstock are shown on Drawing C-1028.…
