Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 720
the arbitrary constants which fix the linearvelocity of the steam. In other words, the steam enters at all angles withthe velocity determined by cylinder volume and port-area, and not by-variation in relation of the crank angles. 93. Consult also Catechism of the Locomotive Engine, by M. N.… … have moved through an angle 00. If r is the radius of the valve-crank, /and h the lengths of the valve-rod to the knuckle-joint and the valve-stem. 684 APPENDIX. proper respectively, then from the diagram in which the line through Xiixes the central position of the valve, the length BX may…
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
