Mechanical laboratory methods; the testing of instruments and machines in the mechanical engineering laboratory and in practice (1922)

Smallwood, Julian Chase · New York, D. Van Nostrand company · leaf 63

An illustration from Mechanical laboratory methods; the testing of instruments and machines in the mechanical engineering laboratory and in practice, 1922, leaf 63 — tionarydial. The dial is arranged to indicate horse-power direct. Another spring dynamometer, made by the Central LaboratorySupply Company, is shown by Fig. 29. Two shafts are connectedby a spring through which the power to be measured is passed.These shafts are provided with discs arranged as… … Driver Shaft

Mechanical engineering

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
