Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 409

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 409
LINE MOTION WITH ONELEVER AND A SLIDINGLINK.—Lever Z is connect-ed to a sliding link F. Z ispivoted at D and connected tolink F at C. F is a link con-nected to Z at C and to a sliding block at A, the other end of which is at B, and moves in a straight line as at 5^. … 1654. STRAIGHT LINE MOTION WITH ONE LEVER AND A SLIDINGLINK.—Lever F is connectedto a sliding link Z. F is pivot-ed at D and connected to Z atC. Z is connected to F at Cto a sliding guide at A, and the end B moves in a straight line.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
