Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 37
lengths, as are the short links, S, L and P, D. 48/. STRAIGHT LINE LIXK-AGE.—With the joints S and Pfixed the joint B will have a ver-trical motion while the link L, Mwill have a horizontal motion paral-lel with the fixed points S. P. LinksP, C, C. ]M. and B, C. are of equalleneth. L. B and L. ^i… … 48;. THE LE\TER AXD ITSOFFICE in the pulley governor.Type of the Shepherd governor, inwhich centrifugal force and inertiaare combined for regulating speed. 4Sk. THE LEAER AXD ITSOFFICE in the pulley governor.Type of the Fitchburgh Steam En-gine Company. The lever weightsW, \\ are thrown out by…
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
