Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 125

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 125
423. SECTIONAL PLAN OF A GASOLINE ENGINE.— Four-cycle type, with exhaust port opened by the piston at the endof the stroke, and continued exhaust through an annular valve aroundthe inlet valve. The charge is heated and vaporized in the valyechamber by the exhaust. Olin model. ii8 MOTIVE POWER. … 424. SIMPLE GAS OR GASOLINE ENGINE.—A, inletvalve ; E, exhaust valve ; gasoline enters by gravity at G, regulatedby a faucet. Air enters at B by the suction of the piston, atomizingthe gasoline as it drops into the air chamber. The tube igniter isheated by a gasoline burner beneath the bell mouth.…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
