Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 268

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 268
^x 1039. SLOTTED YOKE CRANK MOTION, 7^^5 1 producing rectilinear motion of piston rod from a crank dispensing with a connecting rod. … 1040. TRAMMEL GEAR.—The slotted cross movesin a right line astride the shaft, while the crank pin in ablock moves in the cross slot. 1041. SLOTTED LEVER MOTION from a crankpin. A variety of motions and stop motions may bemade with this class of lever.

Mechanical movements
