Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 54
e danger. The Tate flexible stay bolt, which received the high-est award at the St. Louis exposition in J904, appearsto offer at least a partial solution of the problem ofstaying fire-box sheets. Fig. 8 is a sectional viewshowing the design of this stay bolt. The ball-shaped THE BOILER 47 head of… … Figure 8
Locomotives
