ides of the jaw, forming, in effect, aratchet. The lower end of the oscillating jaw is secured to the shaft of the cylinder by flat con-necting bars. In the ends of these bars are heavy set-screws, bearing against the cylinder-shaft, by which the distance between the lower end of the jaw and the… … Dodse crasher. white-iion or steel, which can be reversed from center to side, or end for end, when worn.The eccentric shaft is fitted with two heavy balance-wheels and tight and loose pulleys. The Forster Crusher (Fig. 4) is a coarse-crushing machine of the jaw type. The oscillat-ing jaw is…
