Benjamin, Charles H[enry], 1856- [from old catalog] · Cleveland, C. H. Holmes · leaf 96
Fig. 36. Counter shafts are short and light and are notsubject to much bending. Consequently there is notthe same need of ad-justment as in lineshafting. In Fig, 37 is il-lustrated a simplebearing for counters.The solid cast ironbox B with a sphericalcenter is fitted directlyin a socket in… … 90 MACHINE DESIGNc There is not space here to show the various formsof hangers and floor stands and reference is made tothe catalogues of manufacturers. Hangers should besymmetrical, i. e. the center of the box should be in avertical line with center of base. They should haverelatively broad bases…
Machine design
