On yacht sailing; a simple treatise for beginners upon the art of handling small yachts and boats (1904)
Day, Thomas Fleming, 1861- [from old catalog] · New York and London, The Rudder publishing company · leaf 87
83 SAIL PLAN OF POLE MAST SLOOP. I—Mainsail. 9—Fore staysail tack. 4— peak. 10— clew. 5—• throat. 3—Jib. 6— tack. II— head. 7— clew. 12— tack.2—Fore staysail. 13— * clew. 8— head. … SAIL PLAN OF TOPSAIL SLOOP. 8c, SAIL PLAN OF TOPSAIL SLOOP. I—Mainsail. 14—Jib tack. 6— peak. 15— clew. 7— * throat. 4—Jib topsail. 8— tack. 16— head. 9— clew. 17— tack.2—Fore staysail. 18— * clew. 10— head. 5—Topsail. ii_ - - tack. 19— head. 12— clew. 20— clew.3—Jib. 21— tacko 13— head.Sailing
