Em Fig. 293. Fig. 294. Fig. 295.—Load greater than Light load. Heavy load. the maximum output. Figs. 293-295.—Vector diagram for the synchronous motor at various loads. If the load on the motor is now increased, the motor swingsback relative to the generator by a greater angle 6, as shown inFig.…
