Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 125
true lengths of theelevation with the true widths of the plan.Therefore, at any convenient distance, drawm-n parallel to d-z; project with the trianglesfrom c, e, b, f, etc., at right angles to m-n; andmake the widths Ci-Ci, bi-fj, and aj-gj, equalrespectively to c-e, b-f, and a-g, half of each… … Fig. 72. Eight Cylinder Cut by Plane Perpendicular to V.Development of Cylinder Shown at Eight. cylinder is also shown. As in the case of theplane cutting the cone, elements of the cylinderare drawn, and the points noted in which theplane cuts the elements. The base is here MECHAXICAL DEAFTING 103…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
