height Ci-c, laid off at C2-c\ Thepoint c^ is thus fixed in position by the three MECHANICAL DEAFTING 133 co-ordinates parallel to the isometric axes. Therest of the figure may then be easily finished. 121. Isometric of Curved Lines. Points inthe isometric of circles or other curved lines,are also… … Fig. 88. Illustrating Isometric of Curved Lines. is drawn. The circles will then be constructedin the top and the left front side. Taking first the smaller ciicle in the top,divide it into any number of equal parts, aseight in the figure. The points might be locatedby means of co-ordinates from the…
