e made theexact width where it reste on the string. Thetreads must be made the exact width requiredbefore they are grooved or the nosing worked onthe outer edge. The lip or tongue on the risershould fit snug in the groove and bottom. Byfollowing these last instructions, and seeing thatthe blocks… … FIG. 244 282 PRACTICAL CARPENTRY upper edge of the string, the distance intended tostand above the treads as shown in the dottedline. On this Une apply the pitch-board as ex-plained on previous pages. In laying out housedstrings it is as well to take the fence off the pitch-board, as it can be…
