event the ash dust fromflying back into the room. For supporting thehearth, use iron bars made of % by 2 iron; andon this, lay brick edgewise, leaving a space ofthree or four inches for concrete on which to laythe tile hearth. The fireplace should be lined 84 FRAMING with firebrick, with the upper… … Oi^ Seeoi^d floor. tj^inj?ble at A. -Irom Door Seetioi? tbrou^l^ fire piaee. Fig. 46. Arrangemeut for Fireplace. FRAJVIING 85 it will not show. If a straight-top opening isdesired, then use a 3-inch by 3-inch angle iron,with the flange on the inside of the brickwork. The dotted lines show the…
