Fig. 87. Paneled Finish for Stairs. FRAMING 157 squares to get the proper angle, simply take likefigures on square No. 1, say 10 and 10; placethem so that these figures are at the edge ofthe panel, as shown, and with the heel of squareNo. 2 resting on the former, and with the bladeintersecting the… … Fig. 88. How to Apply Moulding under Stairs The same results may be obtained by bisect-ing the angle with the compass, as shown inthe two lower corners of the enlarged panel inthe lower part of Fig. 87, and setting a bevelsquare to the angles thus formed. This willgive the miter. A more common way,…
