Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 94
Pig. 37. Framing for Exterior Door. FRAMING 71 and contraction will not split them. The mould-ings are nailed to the stiles and rails and a pinefillet is set in between them. The trim is worked out of seven-eighths-inchmaterial, and has a moulded back-band. Thelittle tongue left on back edge of… … riq. A Pig. 38. Sliding Doors—Construction at Jamb. merit. Full directions are furnished with eachset. Any average workman should be able toput up the work. The main thing is to see thatthe partition rests on substantial bearings toprevent settlement, as this will necessarilythrow the track out of…
