Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 175
drawers will be divided into smaller compartments. By making the top tillthe same length as the drawers there is a pocketat each end which can be utilized for special tools.Besides the outside lock which each drawer shouldhave, there should be a locking device on the in-side at the front end of the… … ^4%n FLOOR PLAN OP TENT SECTION SHOWING INTERIOR PLATE 161 B—TUBERCULOSIS CAMP TENT Floor plan and cross section showing details of double cloth over a light wood frame. The three arrangement and construction for a sanitarium sides of the tent containing the windows and built- tent for the…
Building · Architecture
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
